About the Sheet Metal Fabrication Process for Kitchen Equipment:
1. Core Process
—Cutting Stage: A 12kW fiber laser cutting machine is used to process 40mm thick plates with an accuracy of ±0.1mm, making it particularly suitable for cutting complex contours of stainless steel kitchenware.
Shearing machines are used for straight-line cutting, and punching is suitable for mass production of standard parts.
—Forming Process: A 200-ton press brake achieves ultra-long bends of up to 4 meters, allowing for multi-pass shaping of stainless steel sheets within 6mm.
Commercial kitchen equipment typically uses 1.2-1.5mm stainless steel sheets for bending and forming.
—Welding Technology: TIG spot welding combined with laser welding/double-container welding increases weld strength by 30%, meeting the requirements of National Standard T19804.
Welding for food equipment must ensure contamination-free operation.
2. Material Selection Specifications
--Main Material: Commercial equipment typically uses 304 food-grade stainless steel (1.0-1.5mm thickness), while economy products utilize 0.6-1.0mm galvanized steel.
--Special Components: Water heater tanks utilize 304 stainless steel, and decorative strips utilize 6063-T5 aluminum alloy.
--Surface Treatment: Powder coating (30-80μm film thickness) or brushed/mirror polish. Must pass a 1000-hour salt spray test.
3. Quality Inspection System
--Dimensional Inspection: Coordinate measuring machines ensure mounting hole accuracy of ±0.05mm.
--Weld Inspection: X-ray inspection detects internal cracks.
--Coating Inspection: Paint film thickness gauges control within a 30-80μm range.
--Assembly Inspection: Laser scanners verify joint uniformity.
4. Typical Equipment Processing Cases
--Commercial Refrigerator: 0.6-1.0mm cold-rolled sheet metal bending, powder coating
--Disinfection Cabinet Housing: 1.2mm stainless steel laser cutting and bending, argon arc welding
--Coffee Machine Components: 0.8mm galvanized sheet metal stamping, brushed finish
Our processing capabilities
As an excellent custom sheet metal manufacturer, we have the following advantages. Explore different sheet metal fabrication solutions based on advanced manufacturing capabilities to meet your custom metal fabrication needs.
Laser Cutting
Our laser cutting technology ensures precision, clean edges, and minimal waste for intricate designs and tight tolerances.
Metal Bending
We provide metal bending services with advanced machinery to shape metals without compromising structural integrity.
Stamping
Our sheet metal stamping shapes metal into precise forms, perfect for large quantities of identical, high-quality parts.
Our Advantages
Experienced Fabricator
Drawing on decades of experience, we provide high-quality sheet metal fabrication services that meet industry standards.
In-House Equipment
Our factory utilizes advanced technology, ensuring faster production and enhanced quality control for every project.
Quality Inspection
We ensure quality by inspecting each component to ensure it meets customer specifications before it leaves our factory.
Sheet Metal Expertise
Work with our engineers for design advice, manufacturability insights, and cost-saving tips.
Our sheet metal factory
Available Materials for Sheet Metal Fabrication
Here is a list of our standard available metals for sheet metal fabrication. If you require a custom material please contact us via email.
| Material | Subtypes |
|---|---|
| Aluminum | Aluminum 5052, Aluminum 5083, Aluminum 5754 |
| Copper | Copper C101, Copper C103, Copper C110, Copper C260 (Brass) |
| Stainless Steel | 301, 304, 316, 316L |
| Steel | SPCC, Galvanized Steel (SGCC / SECC), Q235, Steel 1020 |
| Equipment | Brand | Quantity |
|---|---|---|
| CNC Laser Cutting Machine | Mitsubishi ML3015SR-f20ML3015GX-F40 | 3 |
| CNC Laser Cutting Machine | Mitsubishi ML3015eX | 3 |
| CNC Laser Cutting Machine | BaiChao DiNeng 3000W | 4 |
| CNC Bending Machine | Amada RG80 | 5 |
| CNC Bending Machine | Tongyang APB-3613WU | 2 |
| CNC Bending Machine | Tongyang HYB-6020 | 3 |
| CNC Bending Machine | Tongyang APB-5620WU | 4 |
| CNC Bending Machine | Osmar OSM 0G-60III | 6 |
| 600T Press | Yihui YHA4-600T | 3 |
| 400T Press | Y34-400T | 4 |
| 300T Press | Yihui YH-300T | 3 |
| 160T Press | Shengze SJ-160T | 5 |
| 100T Press | Shengze SJ-100T | 5 |
| 250T Stamping Machine | Xieyi SN2-250 | 5 |
| 110T Stamping Machine | Jinfeng COP-110N | 10 |
| 80T Stamping Machine | Xieyi SN1-80 | 5 |
| 618 Riveting Machine | Haeger-618PLUS-H | 15 |
| 617 Riveting Machine | HAIGEH 617 | 10 |
| 416 Riveting Machine | Haeger-416-220 | 5 |
| Handheld Laser Welding Machine | Fenghuo WSM-400 | 2 |
| Welding Machine | Yili NBC315 | 3 |
Tolerances for Sheet Metal Fabrication Services
Listed below are the standard tolerances achieved for parts produced by our in-house sheet metal factories.
| Feature | Tolerance |
|---|---|
| Cutting feature | From ±0.002" (0.05 mm) |
| Bend angle | From ±1.0° |
| Bend to edge | From ±0.004" (0.1mm) |
Sheet Metal Fabrication is a comprehensive cold processing process for metal sheets (usually less than 6mm), including shearing, punching/cutting/compositing, folding, riveting, splicing, forming (such as automobile bodies), etc. Its distinctive feature is that the thickness of the same part is consistent.
MoreSheet metal processing has been widely used in electronic appliances, communications, automotive industry, medical equipment and other fields. For example, in computer cases, mobile phones, and MP3 players, sheet metal components is an essential component.
MoreSheet Metal Fabrication Services Custom sheet metal fabrication services using advanced technology for prototyping or large-scale production. Partner with us for efficient, cost-effective, and reliable solutions today! Post-processing options such as annealing, powder coating, etc. Over 30 metals Free quoting and design feedback
